Custom LED lighting cable harnesses for connecting lights, LED modules, switches and control components. Fengzhan supports customized wire lengths, connectors, branch structures and terminations for lighting equipment.
Fengzhan manufactures customized LED lighting cable harnesses designed for connecting LED modules, lighting fixtures, switches and control components. The harness can be configured with different wire lengths, connectors, branch structures and termination methods to meet various lighting system requirements.
From simple single-light connections to multi-point lighting applications, our solutions help provide organized wiring, stable connections and efficient assembly for OEM lighting equipment.
LED lighting systems may require more than a simple power connection. Wiring can distribute electrical power, connect multiple light modules, integrate switches or controls, and organize branch circuits within the equipment. Fengzhan can configure the harness around the required lighting layout, electrical connections and installation structure.
Provides wiring between the lighting power source and LED modules or fixtures according to the specified electrical requirements.
Connects multiple LED lights or modules through a common wiring structure, helping organize power connections across different lighting points.
Supports connections between LED lighting and switches, dimming controls or other control interfaces when required by the equipment design.
Connects separate LED modules within the same lighting system using customized wire lengths, connectors and branch arrangements.
If your lighting project requires dedicated wiring for switches, buttons or control inputs, our Switch Wire Harness Assembly is designed around these interface requirements. It can be configured with different wires, terminals, connectors and cable lengths according to the equipment design.
For complete LED lighting interconnections, including light modules and branch wiring, continue with our LED Lighting Cable Harness solutions.
Lighting harnesses can be built in different structures depending on the number of lights, connection points and available installation space. Fengzhan supports simple lead configurations as well as multi-branch assemblies with customized connectors, terminals, wire lengths and circuit arrangements.
A simple cable structure connecting a power or control interface directly to one LED light or lighting module.
A main cable can be divided into multiple branches to connect several LED lights or modules within the same lighting system.
Connectors can be installed according to the interface requirements of individual LED modules, allowing easier assembly and replacement.
One harness can combine connectors, terminals and wire leads where different connection methods are required within the lighting equipment.
LED lighting harnesses often need to fit around multiple light sources, control points and installation locations. Fengzhan can configure the wiring structure according to the physical layout and electrical requirements of the lighting system, helping keep connections organized while simplifying assembly and installation.
Supports customized branch structures for connecting multiple LED modules or lighting points.
JST, Molex and other connector types can be considered according to the required mating interface.
Wire lengths and branch positions can be configured around the physical layout of the lighting equipment.
Supports connector, crimp terminal, wire lead and other termination configurations.
The harness structure can be adapted to limited spaces inside lighting fixtures and equipment.
Wire colors, labels and defined wire sequences can be used to help identify different lighting or control circuits when required.
Fengzhan can manufacture lighting harnesses around your fixture structure, LED module arrangement and electrical connection requirements. Cable length, wire gauge, conductor quantity, connector type, branch structure, terminal configuration, wire sequence and protective materials can all be specified according to your design. Drawings, wiring diagrams, connector specifications or samples can be provided for project review.
- Cable length
- Wire quantity
- Wire gauge
- Cable color
- Pin configuration
- Connector selection
- Terminal type
- Housing selection
- Pin arrangement
- Connector replacement
- Heat shrink protection
- Braided sleeving
- Shielding layer
- Waterproof sealing
- Special insulation materials
- OEM Design
- Prototype development
- Low-volume production
- High-volume manufacturing
- Customized packaging
Fengzhan controls the harness manufacturing process from incoming materials through wire processing, terminal crimping, connector assembly and final inspection. Production checks focus on wiring configuration, crimp quality, connector installation, cable length and electrical continuity to help ensure that finished assemblies match the confirmed specifications.
All incoming wires, connectors, terminals, and components are inspected to verify specifications, material quality, and compliance before entering the production process.
Wire cutting processes are carefully monitored to ensure accurate length, stripping dimensions, and consistent preparation for reliable assembly performance.
Crimping operations are inspected to ensure proper terminal connection, pull strength, and stable electrical performance according to production requirements.
Connector installation is checked to confirm correct pin positions, secure connections, and proper assembly quality for dependable cable performance.
Each cable assembly undergoes electrical testing to verify continuity, wiring accuracy, and reliable signal or power transmission before shipment.
Finished products are visually inspected for appearance, labeling, protection, and overall assembly quality to ensure they meet customer specifications.
FAQ 1
Can one harness connect multiple LED lights or modules?
Yes. A multi-branch structure can be designed to connect multiple LED lights or modules from a common wiring assembly. The number of branches, cable lengths and connector configuration can be defined according to the lighting system layout.
FAQ 2
How should the wiring be arranged for multiple lighting points?
The wiring structure depends on the location of the LED modules, available installation space and required connection method. Customers can provide a layout or wiring diagram, allowing the branch positions and cable lengths to be configured around the equipment structure.
FAQ 3
Can the harness include connections for LED switches or controls?
Yes. A lighting harness can incorporate wiring for switches or control interfaces when required. The wire configuration, connector or terminal type and circuit arrangement can be specified according to the control system.
FAQ 4
Can different connectors or terminals be used in the same lighting harness?
Yes. Different termination methods can be incorporated when the lighting system requires multiple interface types. Connector models, terminals and wire leads can be configured according to the mating components and assembly requirements.
FAQ 5
Can you build the harness from an existing LED lighting sample?
Yes. An existing harness, connector sample, wiring diagram or product drawing can be used as a reference for developing a new assembly. Fengzhan can review the available information and confirm the wiring structure before prototype production.
